Supplier One-Click Vision Measuring Machine for Gears Screws Electronics Small Parts MSS-A-XUY-TD21191 Digital Microscope

Calibration : Factory Calibrated

Display Type : LCD Screen Display

customized support : ODM, OEM

warranty : 1 Year

Logo/graphic design : no

Focusing Distance : 25 mm

Model Number : MSS-A-XUY-TD21191

External Display Support : Yes

Place of Origin : Shanghai, China

dimension : Custom Sizes

illumination : LED

Dioptric Adjustment : other

IP Rating : IP20

Brand Name : MSS

MOQ : 1

Focus Type : Auto Focus

Price : $3,550-3,750

type : Desktop flash tester

camera resolution : Other

Contact Now

Product descriptions from the supplier

Simple and easy to use, achieving one click fast and accurate measurement;

Automatic positioning of measurement objects, matching templates, measurement evaluation, and report generation;

Suitable for flat and rotating workpieces, meeting the measurement requirements of different specifications and types of products;

Combining dual telecentric lenses, high-resolution industrial cameras, and high-precision image analysis and processing algorithms;

Small products such as gears, hardware products, terminals, screws, electronic products, stamping products, plastic products, automotive parts, medical equipment, etc

Productparameters

Device Type Vertical flash tester
host dedicated machine
Display Size 21.5-inch, 1080P
Industrial Camera 20 million pixel USB 3.0
Industrial lens 0.108x dual telecentric lens
Lighting System Far center parallel light source (green)
Auxiliary light source 170 ring light (white)
measuring range 100*80mm
measurement accuracy 3um+L/100um
Display units 0.1um
software system Flash Tester Special Software
Input power supply AC220V,2A
Equipment size 215*440*635mm
Productspecifications
Eguipmentmodel confiauration
SC100-80 20millionUSBblackandwhite +0.109timestelecentrio +lowliaht+positiveliaht
Optional size
Loadglass 120*120*8mm
Calibrationboard 120*120*3mm
